Flextrans supplies Haul-off belts for all types of extruders, including haul-off for cables, wires, pipes and profiles.
Haul-offs" are pulley-driven parallel belts that contact opposite sides of in-process products, usually by means of rollers exerting suitable pressure for the belts to grip and haul them, with the desired controlled pulling action.
Our range includes specific combination of base belts, tensile strengths and fabrication details to meet technical requirements of variety of extrusion applications, including specific resistance, hardness, temperature, friction needs.
Flextrans supplies Haul-off belts for all types of extruders, including haul-off for cables, wires, pipes and profiles.
Haul-offs" are pulley-driven parallel belts that contact opposite sides of in-process products, usually by means of rollers exerting suitable pressure for the belts to grip and haul them, with the desired controlled pulling action.
Our range includes specific combination of base belts, tensile strengths and fabrication details to meet technical requirements of variety of extrusion applications, including specific resistance, hardness, temperature, friction needs.
Type:
1. Flat belt
2. Ribbed belt
3. With groove on the surface
Feature:
Flame-Retardant, Anti-Static, Oil-Resistant, Cold-Resistant, Corrosion-Resistant, Heat-Resistant, Alkali-Resistant, Skid-Resistance, Wear-Resistant, Acid-Resistant, High Temperature-Resistance, Seamless/ Wear-Resisting
Application:
Textile Machinery, Garment Machinery, Conveyor Equipment, Packaging Machinery, Electric Cars, Food Machinery, Marine, Mining Equipment, Agricultural Machinery
Physical Properties | |
Specification (Inner Length, Width, Thickness) | Customized |
Colors | Black,White,Red,Green,Grey or Customized |
Breaking strength | 500 ~ 2000 daN/cm |
Max. length | 25,000mm |
Max. belt thickness | 40mm |
Traction Layer | Rubber: Imported NR |
Bottom layer | Rubber: CR; Reinforcement: Polyester Cord + Fabric |
Mechanical Properties | High breaking load |
High Wear Resistance | |
Low Elongation at Working Load | |
Aging Proof | |
Hardness | 60°± 5°(cable traction) |
50°± 5°(optical cable; plastic and pipe Traction etc.) | |
80°± 5°(custom) | |
Max. temperature | +100℃ |
Processing | Rubber Mixing, Winding, Rubber Adding,Cutting, Grinding, QC, Packaging and Delivering |
